Circuit design is the core of APIS DAQ. Ultra-low latency, Ultra-low power technology is essential for device development.
Beginning with the First gen test board, APIS developed the second MVP model, and the prototype will be developed shortly.
Test Board 1
- TFT LCD
- STM32 Series
- Power control
- USB-C
- Micro USB
- Lightning Connector
- Bluetooth 4.2
- Wi-Fi
Test Board 2
- TFT LCD
- STM32 Series
- Power control
- USB-C
- Micro USB
- Lightning Connector
- Bluetooth 4.2
- Wi-Fi
- Micro SD
- CO
- NO2
- SO2
- O3
- PM
- UV
- Temperature
- Humidity
MVP – ver 1.0
- STM32 Series
- Power control
- USB-C
- Wi-Fi
- CO
- NO2
- SO2
- O3
- PM
- UV
- Temperature
- Humidity
MVP – ver 2.0
- STM32 Series
- Power control
- Micro USB
- Wi-Fi
- Micro SD
- CO
- NO2
- SO2
- O3
- PM
- UV
- Temperature
- Humidity
MVP – ver 3.1
- Power control (12V)
- USB-C
- LTE Cat.M1
- Wi-Fi
- CO
- NO2
- SO2
- O3
- PM
- UV
- Temperature
- Humidity
MVP – ver 3.2
- Power control (12V)
- USB-C
- LTE Cat.M1
- Wi-Fi
- CO
- NO2
- SO2
- O3
- PM
- UV
- Temperature
- Humidity
MVP – ver 3.3
- Power control (12V)
- USB-C
- LTE Cat.M1
- Wi-Fi
- CO
- NO2
- SO2
- O3
- PM
- UV
- Temperature
- Humidity
Power Board 1.0
- Solar Panel
- Li-ion
- 12V control
Main Board 1.0
- Power control (12V)
- USB-C
- LTE Cat.M1
- Wi-Fi
Sensor Board 1.0
- CO
- NO2
- SO2
- O3
- PM
- UV
- Temperature
- Humidity
Slot Board 1.0
- 5″ capacitive touch Display
- Control Power / Main / Sensor board
